Specifications & Characteristics:
- Complete hand-made, using high quality raw materials.
- Ozone & Oil Splash Resistant
- Size: ID 6 mm – ID 203 mm (ID 1/4″ – ID 8″)
- Layers: Polyester Fabric Reinforcement
- Working Temp Range: -50 °C ~ 180 °C (-120 °F ~ 360 °F)
- Colors: Blue, Black, Red, Orange, Green, Gray
- Available with Fluorosilicone or Fluorocarbon Liner
- Standard: SAE J20
- Ozone & Oil Splash Resistant
- OEM logo printed on hose
Tell us which parts do you need?
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length x2 mm (inch) |
| DS-180E006 | 6 (1/4) | 3 (0.118) | 2 | 100 (4) |
| DS-135E008 | 8 (5/16) | 3 (0.118) | 2 | 100 (4) |
| DS-180E010 | 10 (3/8) | 3 (0.118) | 2 | 100 (4) |
| DS-180E012 | 12 (1/2) | 4 (0.157) | 3 | 100 (4) |
| DS-180E014 | 14 (9/16) | 4 (0.157) | 3 | 100 (4) |
| DS-180E016 | 16 (5/8) | 4 (0.157) | 3 | 100 (4) |
| DS-180E018 | 18 (11/16) | 4 (0.157) | 3 | 100 (4) |
| DS-180E020 | 20 (13/16) | 4 (0.157) | 3 | 100 (4) |
| DS-180E022 | 22 (7/8) | 4 (0.157) | 3 | 100 (4) |
| DS-180E025 | 25 (1) | 4 (0.157) | 3 | 100 (4) |
| DS-180E028 | 28 (1-1/8) | 4 (0.157) | 3 | 100 (4) |
| DS-180E030 | 30 (1-1/6) | 4 (0.157) | 3 | 100 (4) |
| DS-180E032 | 32 (1-1/4) | 4 (0.157) | 3 | 100 (4) |
| DS-180E035 | 35 (1-1/3) | 4 (0.157) | 3 | 100 (4) |
| DS-180E038 | 38 (1-1/2) | 4 (0.157) | 3 | 100 (4) |
| DS-180E041 | 40 (1-5/8) | 4 (0.157) | 3 | 100 (4) |
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length x2 mm (inch) |
| DS-180E045 | 45 (1-3/4) | 4 (0.157) | 3 | 100 (4) |
| DS-180E051 | 51 (2) | 5 (0.197) | 4 | 100 (4) |
| DS-180E057 | 57 (2-1/4) | 5 (0.157) | 4 | 100 (4) |
| DS-180E060 | 60 (2-3/8) | 5 (0.157) | 4 | 127 (5) |
| DS-180E063 | 63 (2-1/2) | 5 (0.157) | 4 | 127 (5) |
| DS-180E067 | 65 (2-5/8) | 5 (0.157) | 4 | 127 (5) |
| DS-180E070 | 70 (2-3/4) | 5 (0.157) | 4 | 127 (5) |
| DS-180E076 | 76 (3) | 6 (0.236) | 5 | 127 (5) |
| DS-180E080 | 80 (3-1/8) | 6 (0.236) | 5 | 127 (5) |
| DS-180E083 | 83 (3-1/4) | 6 (0.236) | 5 | 127 (5) |
| DS-180E089 | 89 (3-1/2) | 6 (0.236) | 5 | 127 (5) |
| DS-180E095 | 95 (3-3/4) | 6 (0.236) | 5 | 127 (5) |
| DS-180E102 | 102 (4) | 6 (0.236) | 5 | 127 (5) |
| DS-180E114 | 114 (4-1/2) | 6 (0.236) | 5 | 127 (5) |
| DS-180E127 | 127 (5) | 6 (0.236) | 5 | 127 (5) |
| DS-180E152 | 152 (6) | 6 (0.236) | 5 | 127 (5) |
