Specifications & Characteristics:
- Premium Fuel hose is made of the material fluororubber FKM Rubber (excellent Fuel, high temp., UV and Ozone resistant).
- Size: ID 3 mm – ID 25 mm (ID 1/9″ – ID 1″)
- Layers: No layer or 1 AR Reinforcement
- Working Temp Range: -30 °C ~ 250 °C (-90 °F ~ 480 °F)
- Colors: Black is the most common color, others are available.
- High / Low pressure.
- Standard: SAE J30 R10
- OEM logo, words, size data printed on hose
Tell us which parts do you need?
No Layer reinforced
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length m (foot) |
| FKM0-0204 | 2 (2/25) | 1 (0.039) | 0 | 100 (328) |
| FKM0-0205 | 2 (2/25) | 1.5 (0.059) | 0 | 100 (328) |
| FKM0-0305 | 3 (1/9) | 1 (0.039) | 0 | 100 (328) |
| FKM0-0306 | 3 (1/9) | 1.5 (0.059) | 0 | 100 (328) |
| FKM0-0407 | 4 (5/32) | 1.5 (0.059) | 0 | 100 (328) |
| FKM0-0508 | 5 (3/16) | 1.5 (0.059) | 0 | 50 (164) |
| FKM0-0609 | 6 (1/4) | 1.5 (0.059) | 0 | 50 (164) |
| FKM0-0711 | 7 (0.275) | 2 (0.079) | 0 | 50 (164) |
| FKM0-0812 | 8 (5/16) | 2 (0.079) | 0 | 50 (164) |
| FKM0-1014 | 10 (3/8) | 2 (0.079) | 0 | 20 (66) |
| FKM0-1216 | 12 (1/2) | 2 (0.079) | 0 | 20 (66) |
| FKM0-1418 | 14 (11/20) | 2 (0.079) | 0 | 30 (98) |
| FKM0-1620 | 16 (5/8) | 2 (0.079) | 0 | 25 (82) |
| FKM0-1925 | 19 (3/4) | 3 (0.118) | 0 | 20 (66) |
Other ID, Wall thickness or Length can be customized by your requirement.
1 Layer reinforced
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length m (foot) |
| FKM1-0308 | 3 (1/4) | 2.5 (0.1) | 1 | 20 (66) |
| FKM1-0410 | 4 (5/16) | 3 (0.118) | 1 | 20 (66) |
| FKM1-0511 | 5 (3/16) | 3 (0.118) | 1 | 20 (66) |
| FKM1-0612 | 6 (1/4) | 3 (0.118) | 1 | 20 (66) |
| FKM1-0713 | 7 (0.275) | 3 (0.118) | 1 | 20 (66) |
| FKM1-0814 | 8 (5/16) | 3 (0.118) | 1 | 20 (66) |
| FKM1-1016 | 10 (3/8) | 3 (0.118) | 1 | 20 (66) |
| FKM1-1218 | 12 (1/2) | 3 (0.118) | 1 | 20 (66) |
| FKM1-1420 | 14 (11/20) | 3 (0.118) | 1 | 20 (66) |
| FKM1-1622 | 16 (5/8) | 3 (0.118) | 1 | 20 (66) |
| FKM1-1926 | 19 (3/4) | 3.5 (0.138) | 1 | 20 (66) |
| FKM1-2532 | 25 (1) | 3.5 (0.138) | 1 | 20 (66) |
Other ID, Wall thickness or Length can be customized by your requirement.
