Specifications & Characteristics:
- Plastic Spiral Hose Guard Wrap is used to protect and bound hydraulic hoses, fuel tubes, cooling system pipes, cables and wires. Which has a variety of excellent properties, such as flame retardant, UV resistance, dust proof, easy to install, oil resistance, acid and alkali resistance, chemical agent resistance, excellent abrasion resistant.
- Material: PP
- Size: ID 6 mm – ID 150 mm (ID 1/4″ – ID 6″)
- Working Temp Range: -30 °C ~ 120 °C (-90 °F ~ 250 °F)
- Color: Black, Red, Yellow, Blue, Green, Gray, Orange
Tell us which parts do you need?
| Part No. | ID mm (inch) | Wall Thickness mm (inch) | Suitable hose/wire OD mm | Length m (foot) / roll |
| DSSG-006 | 6 (1/4) | 1.2 | 6-10 | 50 (165) |
| DSSG-008 | 8 (3/8) | 1.2 | 8-12 | 50 (165) |
| DSSG-010 | 10 (2/5) | 1.4 | 10-14 | 50 (165) |
| DSSG-012 | 12 (1/2) | 1.4 | 12-16 | 50 (165) |
| DSSG-014 | 14 (0.55) | 1.5 | 14-18 | 50 (165) |
| DSSG-016 | 16 (5/8) | 1.8 | 16-20 | 50 (165) |
| DSSG-018 | 18 (3/4) | 1.8 | 18-22 | 50 (165) |
| DSSG-020 | 20 (4/5) | 2.0 | 20-25 | 50 (165) |
| DSSG-022 | 22 (7/8) | 2.0 | 22-27 | 50 (165) |
| DSSG-025 | 25 (1) | 2.3 | 25-30 | 50 (165) |
| DSSG-028 | 28 (1-1/8) | 2.5 | 28-32 | 50 (165) |
| DSSG-030 | 30 (1-1/5) | 2.5 | 30-35 | 50 (165) |
| DSSG-032 | 32 (1-1/4) | 2.5 | 32-38 | 50 (165) |
| DSSG-035 | 35 (1-1/3) | 3.0 | 35-40 | 20 (66) |
| DSSG-038 | 38 (1-1/2) | 3.0 | 35-45 | 20 (66) |
| DSSG-042 | 42 (1-5/8) | 3.5 | 42-50 | 20 (66) |
| DSSG-045 | 45 (1-3/4) | 3.5 | 45-55 | 20 (66) |
| DSSG-050 | 50 (2) | 3.5 | 50-60 | 20 (66) |
| DSSG-055 | 55 (2-1/8) | 4.0 | 55-65 | 10 (33) |
| DSSG-060 | 60 (2-3/8) | 4.0 | 60-70 | 10 (33) |
| DSSG-070 | 70 (2-3/4) | 4.0 | 70-80 | 10 (33) |
| DSSG-076 | 76 (3) | 4.0 | 76-89 | 10 (33) |
| DSSG-080 | 80 (3-1/8) | 4.5 | 80-95 | 10 (33) |
| DSSG-090 | 90 (3-1/2) | 4.5 | 90-110 | 10 (33) |
| DSSG-100 | 100 (4) | 5.0 | 100-120 | 10 (33) |
| DSSG-115 | 115 (4-1/2) | 5.0 | 115-130 | 10 (33) |
| DSSG-127 | 127 (5) | 5.0 | 127-150 | 10 (33) |
| DSSG-150 | 150 (6) | 6.0 | 150-180 | 10 (33) |
