Specifications & Characteristics:
- Vacuum hose designed to avoid collapse under high vacuum operation.
Heater hose designed and engineered to meet high performance requirements specified in various industry standards, DIY intake or radiator cooling system. - Size: ID 4 mm – ID 38 mm (ID 2/13″ – ID 1-1/2″)
- Layers: No layer or 1 or 2 Polyester Fabric Reinforcement
- Working Temp Range: -50 °C ~ 180 °C (-120 °F ~ 360 °F)
- Colors: Blue, Black, Red, Orange, Green, Gray
- Available with Fluorosilicone or Fluorocarbon Liner
- Standard: SAE J20
- Ozone & Oil Splash Resistant, but do NOT transport Oil / Fuel.
- OEM logo printed on hose
Tell us which parts do you need?
Silicone Heater Hose
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length m (foot) |
| DS-H06L1 | 6 (1/4) | 3 (0.118) | 1 | 20 (66) |
| DS-H08L1 | 8 (5/16) | 3 (0.118) | 1 | 20 (66) |
| DS-H8L2 | 8 (5/16) | 4 (0.157) | 2 | 20 (66) |
| DS-H10L1 | 10 (3/8) | 3 (0.118) | 1 | 20 (66) |
| DS-H10L2 | 10 (3/8) | 4 (0.157) | 2 | 20 (66) |
| DS-H13L1 | 13 (1/2) | 3 (0.118) | 1 | 20 (66) |
| DS-H13L2 | 13 (1/2) | 4 (0.157) | 2 | 20 (66) |
| DS-H16L1 | 16 (5/8) | 3 (0.118) | 1 | 20 (66) |
| DS-H16L2 | 16 (5/8) | 4 (0.157) | 2 | 20 (66) |
| DS-H19L1 | 19 (3/4) | 3 (0.118) | 1 | 20 (66) |
| DS-H19L2 | 19 (3/4) | 4 (0.157) | 2 | 20 (66) |
| DS-H22L1 | 22 (7/8) | 3 (0.118) | 1 | 20 (66) |
| DS-H22L2 | 22 (7/8) | 4 (0.157) | 2 | 20 (66) |
| DS-H25L1 | 25 (1) | 3 (0.118) | 1 | 20 (66) |
| DS-H25L2 | 25 (1) | 4 (0.157) | 2 | 20 (66) |
| DS-H28L1 | 28 (1.12) | 3 (0.118) | 1 | 20 (66) |
| DS-H28L2 | 28 (1.12) | 4 (0.157) | 2 | 20 (66) |
| DS-H32L1 | 32 (1-1/4) | 3 (0.118) | 1 | 20 (66) |
| DS-H32L2 | 32 (1-1/4) | 4 (0.157) | 2 | 20 (66) |
| DS-H38L1 | 38 (1-1/2) | 3 (0.118) | 1 | 20 (66) |
| DS-H38L2 | 38 (1-1/2) | 4 (0.157) | 2 | 20 (66) |
Silicone Vacuum Hose
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length m (foot) |
| DS-V03 | 3 (1/8) | 2.5 (0.100) | 0 | 100 (300) |
| DS-V04 | 4 (5/32) | 2.5 (0.100) | 0 | 100 (300) |
| DS-V06 | 6 (1/4) | 2.5 (0.100) | 0 | 100 (300) |
| DS-V08 | 8 (5/16) | 2.5 (0.110) | 0 | 50 (150) |
| DS-V10 | 10 (3/8) | 3 (0.118) | 0 | 50 (150) |
| DS-V13 | 13 (1/2) | 3 (0.118) | 0 | 50 (150) |
| DS-V16 | 16 (5/8) | 3.2 (0.125) | 0 | 20 (66) |
| DS-V19 | 19 (3/4) | 3.2 (0.125) | 0 | 20 (66) |
Quick To Visit Other Hose Detail List
We will do a good job in every process, to ensure that to provide customers with high quality Silicone hose!
