Specifications & Characteristics:
- Spiral Wire Flexible Hose offers a variety of bending shapes with a bending radius of more than 180 degrees.
- Ozone & Oil Splash Resistant
- Size: ID 6 mm – ID 76 mm (ID 1/4″ – ID 3″)
- Layers: Polyester Fabric Reinforcement
- Working Temp Range: -50 °C ~ 180 °C (-120 °F ~ 360 °F)
- Colors: Blue, Black, Red, Orange, Green, Gray
- Available with Fluorosilicone or Fluorocarbon Liner
- Standard: SAE J20
- Ozone & Oil Splash Resistant
- OEM logo printed on hose
Tell us which parts do you need?
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length mm (inch) |
| DS-SF006 | 6 (1/4) | 4 (0.157) | 3 | 1000 (39.4) |
| DS-SF008 | 8 (5/16) | 4 (0.157) | 3 | 1000 (39.4) |
| DS-SF010 | 10 (3/8) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF012 | 12 (1/2) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF016 | 16 (5/8) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF019 | 19 (3/4) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF022 | 22 (7/8) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF025 | 25 (1) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF028 | 28 (1-1/8) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF030 | 30 (1-1/6) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF032 | 32 (1-1/4) | 5 (0.157) | 4 | 1000 (39.4) |
| Part No. | ID mm (inch) | Wall mm (inch) | Layer | Length mm (inch) |
| DS-SF035 | 35 (1-1/3) | 5 (0.197) | 4 | 1000 (39.4) |
| DS-SF038 | 38 (1-1/2) | 5 (0.197) | 4 | 1000 (39.4) |
| DS-SF041 | 41 (1-5/8) | 5 (0.197) | 4 | 1000 (39.4) |
| DS-SF045 | 45 (1-3/4) | 5 (0.197) | 4 | 1000 (39.4) |
| DS-SF51 | 51 (2) | 5 (0.197) | 4 | 1000 (39.4) |
| DS-SF057 | 57 (2-1/4) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF060 | 60 (2-3/8) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF063 | 63 (2-1/2) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF067 | 65 (2-5/8) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF070 | 70 (2-3/4) | 5 (0.157) | 4 | 1000 (39.4) |
| DS-SF076 | 76 (3) | 6 (0.236) | 5 | 1000 (39.4) |
